Not
quite, at the age of five I struggled to paddle a canoe made by
my Dad from the wing tank of a WW2 fighter plane. Not long after
I found myself straining to row clinker hire boats on the promise
that I would bail them free of water.
Often the water would flow in faster than I could bail it out, and
sometimes we rowed into waters where man-eating sharks were still
devouring people (Middle Harbour in Port Jackson). One poor fellow
from the Mediterranean was warned not to dive in and was taken the
instant he hit the water. Then, in the sea scouts I struggled with
heavy hardwood oars to row whaleboats. Really! Were whaleboats so
heavy and clumsy? Apparently so, it was just as hard to row the
replica whale boat to re-enact the trip of Captain Arthur Phillip
8 miles up the Hawkesbury river for the Australian bicentennial
in 1988 (these were not the proper super light weight whaleboats
used to chase whales).
Later I demurred to row a surfboat because of
a bad back but when pressed into service was delighted to find my
bad back cured. I had the experience of coasting into the beach
trailing oars on a wave that a surfboard would find far too shallow
to catch. Then, on to the purposeful rowing of a dinghy as I sailed
around the world. Now here was a boat I could row easily if not
at a great speed. On one occasion I rowed the damn thing 5 miles
to a reef off Tagula Is. in New Guinea, where I had been shipwrecked,
for a spot of spear fishing. I had to turn back when a huge shark
cruised by, as I was about to enter the water.
These days I am consumed with the desire to have
the perfect recreational rowing boat. I discovered the Herreshoff
rowboat and have made about 30 for the islanders to commute from
Dangar Island in the Hawkebury River to the mainland. They seem
to me to be as close to the perfect rowboat as you can get. I have
seen a young mother gaily row in a large chop, daughters and all
disappearing from view as each swell passed by. The image had all
the charm of a Homer Winslow painting. All of this is not only good
for the soul but also the environment.
But a few things bothered me. The boat was great but the oars and
oarlocks were not up to standard. After studying racing oarlocks
I spent a couple of years incorporating their best features into
the design of the Gaco oarlock.
Then the oars needed attention. I still had my
fathers oar made in the 1950’s. They were beautifully made
and showed attention to the structural properties of wood. For instance
the tension side of the loom was thinner than the compression side
(wood is twice as strong in compression as in tension). However,
the taper in most of these old oars did not seem to be as extreme
as engineering considerations allowed (that is, drawing the taper
from 2 ¼” at the oarlock to an imaginary width of zero
at the end of the oar blade). As well most of the oars I had used
required an annoyingly firm grip to stop them rotating as they pulled
against and up the round oarlock. Now, one unintended consequence
of the Gaco was that its broad flat plastic bearing area obviated
the need for a leather or plastic oar protection. As well the shape
of the oarlock allowed a modified D-section oar to hold the blade
vertical in the rowing stroke. The larger section oar at the oarlock
meant it was now stiffer. The loom was made by judicious use of
circular saw and router bits ranging from ½” to 1”
radius. I might add that it was necessary to purchase a variable
speed router for the large diameter bits. The only decent Oregon
without knots I could buy was from a recycled timber yard. These
lengths of 4” by 2” had probably been seasoning for
50 years or so in the roof of a suburban house.
What to do about the blade? At first I considered
using veneers but soon realized it could only be curved in one direction.
So now it is made after much experimentation from fiberglass using,
10 oz. woven roving on the tension side, 4mm coremat and 1 ½”
oz chopped strand mat on the compression side. (chopped strand mat
is superior in compression).
The blades are finished off with white polyurethane
paint and the looms are varnished to give the oars an aesthetic
appeal. They are much more pleasant to use as they are lighter outboard
and the blades have an efficient grip on the water. The most pleasant
surprise is the constant angle the blades keep, vertical to the
water, without any effort on my part.
I have had the opportunity to observe the dynamics
of rowing with my crew of eight galley slaves in the surfboat. It
took some time to train them to take long slow strokes, but when
we were headed by the wind, they reverted to quicker shorter strokes.
Much more energy was used during the shorter strokes as the momentum
of the oar and rower’s body has to be changed more often and
more violently. You can actually feel the wasted effort as you push
on the oar at the beginning of the return stroke. However this extra
effort is partly compensated for by the fact that the middle part
of the oar stroke is the most efficient as it is pushing the water
straight back. At the beginning and end of the stroke the water
is pushed both back and sideways. The short quick strokes have the
extra advantage of keeping the momentum of the boat going against
the headwind.
Much effort is often made to put weight onto the
inboard end of the oar, to reduce the effort of raising and lowering
the oar in and out of the water. Sometimes this is done by leaving
inboard part of the oar a square heavy section or alternately lead
weights are incorporated near the handle. Both these solutions add
to the effort required to change the momentum of the oar at the
beginning and end of the stroke. Seeing as we have so little horsepower
to row with, a better solution offers itself. This involves reducing
the weight of the outboard part of the oar. So far I have done this
by engineering the appropriate taper into the loom, and keeping
the blade as light as possible
I have noticed that experienced rowers take long
slow strokes in calm conditions. For long distance rowing this works
best. However, it is best to vary the length of the rowing stroke
over time as this brings different muscles into use. The end result
of a nice long row is a good sleep and wonderfully strong stomach
and back muscles. To say nothing of how the quiet contemplation
of nature lifts the spirits and abolishes depression.
The materials to make each oar cost less than
$30 and the oars are certainly more aesthetic than the carbon fibre
oars which cost over $500. Then there is the added difficulty of
making the bought oars fit the oarlock. So in the meantime I am
very happy with the present product and still have room for refinement.
Now I am very close to the goal of owning the perfect rowing combination.
What a pleasure it is to gently pull the boat through the water
in such an efficient manner that you can go on and on indefinitely.
|
